# Potential Energy in an External Field

When an external force operates to conduct work, such as moving a body from one location to another against a force like spring force or gravitational force, the work is gathered and stored as potential energy in the body. When an external force is removed, the body moves, acquiring kinetic energy and losing potential energy in equal amounts. As a result, the total kinetic and potential energy are conserved. Conservative forces are those who belong to this group. Spring force and gravitational force are two examples of these forces.

Coulomb force is a conservative force between two (stationary) charges. Both have an inverse-square relationship on distance and differ only in the proportionality constants. The masses in the expression of gravitational law are replaced by charges in Coulomb’s law expression. Thus, like the potential energy of a mass in a gravitational field, the electrostatic potential energy of a charge in an electrostatic field is defined.

Attention reader! All those who say programming isn't for kids, just haven't met the right mentors yet. Join the

Demo Class for First Step to Coding Course,specificallydesigned for students of class 8 to 12.The students will get to learn more about the world of programming in these

free classeswhich will definitely help them in making a wise career choice in the future.

### Potential Energy in an External Field

**The potential energy of a single charge:**

The charges and their locations were previously given as the source of the electric field, and the potential energy of the system of those charges was calculated. The most significant distinction is that now our concerned with the potential energy of a charge (or charges) in an external field. The specified charge(s) whose potential energy want to calculate does not produce the external field E. E is generated by sources outside the provided charge (s). External sources may be identified, however, they are frequently unknown or unspecified.

Assume that the charge q does not affect the sources that generate the external field. This is true if q is very tiny, or if unspecified forces hold the external sources in place. Even if q is limited, its impact on external sources may be overlooked in the case of extremely powerful sources far away at infinity producing a finite field E in the region of interest.

From point to point, the external electric field E and the related external potential V may differ. V at a point P is defined as the work required to deliver a unit positive charge from infinity to point P. As a result, the amount of work required to transport a charge q from infinity to point P in the external field is qV.

This work is stored in the form of the potential energy of q. If the point P has position vector r relative to some origin can be written as,

The potential energy of q at r in an external field = qV(r)

where V(r) is the external potential at point r.

Thus, if an electron with charge q = e = 1.6×10^{–19} C is accelerated by a potential difference of ∆V = 1 volt, it would gain energy of q∆V = 1.6 × 10^{–19 }J.

This unit of energy is defined as 1 electron volt or 1eV,

i.e. 1 eV=1.6 × 10^{–19 }J.

**The potential energy of a system of two charges in an external field:**

The potential energy of a system of two charges q_{1} and q_{2} located at r_{1} and r_{2}, respectively, in an external field. To begin, compute the amount of work required to get the charge q1 from infinite to r1. q_{1} V(r_{1}) is the work done in this step. After that, the work that went into getting q_{2} to r_{2}. Work is done against the external field E and the field created by q_{1} in this phase.

Work done on q_{2} against the external field = q_{2}V(r2 )………………………………………..(1)

Work done on q_{2} against the field due to q_{1} is equal to (q_{1}q_{2}/4πε_{o}r_{12} ) ………………………….(2)

where r12 is the distance between q_{1} and q_{2}. By the superposition principle for fields, add up (equation (1) and equation (2))the work done on q_{2 }against the two fields (E and that due to q_{1 }).

Work done in bringing q_{2 }to r_{2} is equal to q_{2}V(r_{2 }) + (q_{1}q_{2}/4πε_{o}r_{12} )

Thus, Potential energy of the system = the total work done in assembling the configuration

= q_{1}V(r_{1} ) + q_{2}V(r_{2} ) + (q_{1}q_{2}/4πε_{o}r_{12} ) ……………………………………….. (3)

**The potential energy of a dipole in an external field**

Suppose a dipole with charges q1 = +q and q2 = –q is placed in a uniform electric field E. The dipole feels no net force in a homogeneous electric field but does experience a torque defined as

τ = p × E.

which will tend to rotate it. Assume that an external torque τ_{ext} is applied in such a way that it simply neutralizes the torque and rotates it in the plane of paper at an infinitesimal angular speed and without angular acceleration from angle θ_{0 }to angle θ_{1}. The amount of work done by the external torque can be written as,

This work is saved as the system’s potential energy. The potential energy U(θ) can then be linked to the dipole’s inclination θ. There is a degree of freedom in choosing the angle at which the potential energy U is regarded to be zero, just as there is with other potential energies. Taking θ_{0} = π/ 2 is a natural decision.

This expression can alternately be understood also from Equation (3). apply Equation (3) to the present system of two charges +q and –q.

……(4)

The location vectors of +q and –q is denoted by r_{1} and r_{2}. The work done in transporting a unit positive charge against the field from r_{2} to r_{1 }is now equal to the potential difference between positions r_{1} and r_{2}. 2a×cosθ is the displacement parallel to the force.

Therefore, [V(r_{1}) – V(r_{2})] = -E×2a×cosθ

So, equation (4) can be written as,

Note that, U′(θ) differs from U(θ) by a quantity which is just a constant for a given dipole.

### Electrostatic Potential

Consider any static charge setup in general. The potential energy of a test charge q is defined in terms of the work done on it. Because the force at any place is qE, where E is the electric field at that point due to the given charge arrangement, this work is obviously proportional to q. As a result, it is convenient to divide the work by the amount of charge q, resulting in a quantity that is independent of q. In other words, work done per unit test charge is representative of the electric field linked with the charge configuration. This reaches the idea of electrostatic potential V due to a given charge configuration. The Work done by external force in carrying a unit positive charge from point R to P can be expressed as,

where, VP and VR are the electrostatic potentials at P and R, respectively.

“The work done by an external force to carry a unit positive charge from infinity to a location is equal to the electrostatic potential (V) at that point.”

In other words, the electrostatic potential (V ) at any location in an area with an electrostatic field is the work required to transport a unit positive charge from infinity to that location (without acceleration). Electric potential energy is a scalar quantity with no direction and only magnitude. It is symbolized by V and has the dimensional formula ML^{2}T^{-3}A^{-1}.

### Sample Problems

**Problem 1: Derive an expression for the total work done in rotating an electric dipole through an angle θ in a uniform electric field?**

**Solution:**

The expression for the torque can be written as,

T = PE sinθ

If an electric dipole is rotated through an angled against the torque acting on it, then small amount of work done is

dw =Tdθ = PE sinθ dθ

For rotating through on angle θ, from 90

^{o},

**Problem 2: A system consisting of two charges 8 µC and –6 µC (and with no external field) placed at (–9 cm, 0, 0) and (9 cm, 0, 0) respectively. Determine how much work is required to separate the two charges infinitely away from each other?**

**Solution:**

Given,

The value of two charges are 8 µC and –6 µC.

Distance between them is 0.18 m.

The expression for the potential energy of a system of two charges q

_{1}and q_{2}can be written as,Substitute the value in the above expression,

W = U

_{2}– U_{1}W = 0 – U

W = 0 – (–2.4)

W =2.4 J.

**Problem 3: Two charged conducting spheres of radii a and b are connected to each other by a wire. What is the ratio of electric fields at the surfaces of the two spheres? Use the result obtained to explain why charge density on the sharp and pointed ends of a conductor is higher than on its flatter portions.**

**Solution:**

Let a be the radius of a sphere A, QA be the charge on the sphere, and CA be the capacitance of the sphere. Let b be the radius of a sphere B, QB be the charge on the sphere, and CB be the capacitance of the sphere. Since the two spheres are connected with a wire, their potential (V) will become equal.

Let EAbe the electric field of sphere A and EB be the electric field of sphere B. Therefore, their ratio,

Since, \frac{Q_A}{Q_B}=\frac{C_AV}{C_BV} and

There fore the equation (1) can be expressed as,

**Problem 4: What is the area of the plates of a 2 F parallel plate capacitor, given that the separation between the plates is 0.5 cm? [You will realize from your answer why ordinary capacitors are in the range of µF or less. However, electrolytic capacitors do have a much larger capacitance (0.1 F) because of very minute separation between the conductors.]**

**Solution:**

Given,

Capacitance of a parallel capacitor, V = 2 F.

Distance between the two plates, d = 0.5 cm = 0.5×10

^{-2}m.Capacitance of a parallel plate capacitor is given by the relation,

C = ε

_{o}A/dWhere,

ε

_{o}= Permittivity of free space = 8.85×10^{-12}C^{2}N^{-1}m^{-2}.A= (2×0.5×10

^{-2})/8.85×10^{-12}=1130 km

^{2}Hence, the area of the plates is too large. To avoid this situation, the capacitance is taken in the range of µF.

**Problem 5: What is the work done in moving a test charge q through a distance of 1 cm along the equatorial axis of an electric dipole? **

**Solution:**

Since potential for equatorial axis is zero that is

V = 0

Therefore,

W = qV = 0

**Problem 6: Define the term ‘potential energy of charge ‘q’ at a distance V in an external electric field. **

**Solution:**

It is defined as the amount of work done in bringing the charge from infinity to its position in the system in the electric field of another charge without acceleration.

V = Er.

**Problem 7: A hollow metal sphere of radius 5 cm is charged such that the potential on its surface is 10 V. What is the potential at the center of the sphere?**

**Solution: **

The electric field inside the shell is zero. This implies that potential is constant inside the shell (as no work is done in moving a charge inside the shell) and, therefore, equals its value at the surface, which is 10 V.
